Torque Corded Electric Screwdriver to Help Tighten Some Household Items PS635
Overview Product Parameters Torque Corded Electric Screwdriver to Help Tighten Some Household Items Ps635 TGK Small Elec
Send your inquiryDESCRIPTION
OverviewBasic Info.
Model NO. | PS635 |
Power Source | Electricity |
Function | Professional, Household |
Condition | New |
Customized | Customized |
Tapping Screw | 2.6-4 |
Product Name | Best Quality Industrial Professional Adjustable Po |
No-Load Speed(Rpm) | 900-1350 |
Machine Screw() | 2.6-4.5 |
Torque Range(N*M) | 0.5-3.5 |
Trademark | TGK |
Origin | Guagndong, China |
HS Code | 8467299000 |
Production Capacity | 10000pieces/Weeks |
Product Description
Product ParametersTorque Corded Electric Screwdriver to Help Tighten Some Household Items Ps635
Product Name | Power Tools Industrial Electric Screwdriver |
Input voltage | AC100-240V |
Rated power | 35W |
Power Adapter | EP860E |
Torque range | 0.5-3.5n*m |
Torque adjustment method | Adjustment sleeve adjustment (up becomes larger, down becomes smaller) |
Range of rotation | 900-1350rpm |
Speed adjustment method | By turning the knob of the power adapter |
Interface | GB 3 plug |
DC Cable Specifications | 3Px0.5mm²x1.8m |
Power Cord Specifications | 3Px0.5mm²x0.5m |
Start method | Press the red lever to start, release to stop |
Direction switch | Third gear (up: reverse; middle: stop; down: forward) |
Batch size | Compatible with all TGK φ6 wind batches (6.35mm hexagon) specification batches |
Batch installation | Press the locking sleeve, align the card slot into the batch nozzle, release the locking sleeve |
Motor | 555 motor (flat shaft) |
When the torque reaches the set value, the motor stops rotating, effectively preventing the screw from slipping | |
Main feature | Ergonomic handle, comfortable to hold, no fatigue during long-term work |
Just touch the start-stop switch, which saves time and effort and improves efficiency | |
The torque is adjusted steplessly from small to large, and the torque is accurate | |
Three-speed directional switch, easy to remove and fasten screws, convenient and fast |
TGK Small Electric Screwdrive Super Value Version series Performance:
1.It is automatically electric screwdriver, when the torque is locked, the cluth will automatically trip, the motor power will be automatically off and the electric screwdriver will stop running.
2.Compared with other model, it is a super value type, lower price, high performance. but please notice that the motor come with out sensor, so it will start slower and more heat.
3. Non-contact switch is used to provide a durable life in which there is no necessity to replace the item often.
Ergonomic size, high temperature durable, weak vibration, good grip, new appearance, light weight, easy to operate for a long time without fatigue, improve efficiency.
4.High precision of the torque, with step-less torque adjustment, simple and efficiently operation, it can be generally used for electrical and electronic lightening products,home appliances, toys, computer/ phone/ watches accessories and other processing and assemblying operations,
CertificationsFAQ
Q: Which kind of products do you offer?
A: We provide all kinds of products, such as heat gun, soldering station, electric screwdriver and plastic welding gun.
Q:Can you design the product according to my requirement?
A:Yes,we can do what you need base on your specifications.
Q:What is the payment term?
A:We currently accept T/T,Westren Union,Escrow.
Q:How long about the bulk production lead time?
A: 7 days after you confirm the samples.
